LEMKEN Primus-12 - Compressed Air Brake

Layout and description
45
5.4.2 Compressed air brake
Overview
1 Compressed air tank
2 Drain valve
EU type-approved air brake system
3a Double release valve – mano-
euvring valve
3b Double release valve – park valve
4 Brake force regulator
Combination brake cylinder (5) with:
 Guiding screw (6)
 Holder (7) for the guiding screw
 Piston rod (8)
 Brake lever (9)
1
2
4
3b
3a
9
8
5
7
6
