Technical data
224
11.2.2 Minimum weights
Weighing is required to determine the exact tare weight.
11.2.3 Permitted weights
Implement with compressed air brake – worldwide *
Implement without braking system – outside the EU
Implement
Axle load [kg]
Drawbar load [kg]
Gross weight [kg]
2500
6100
1750
7850
2500 **
5800
7550
3500
6100
7850
3500 **
5800
7550
4500
7850
9550
* does not apply to Germany and France.
** with the exception of wheel 270/95 R48 145 A8
Implement with hydraulic braking system
Implement
Axle load [kg]
Drawbar load [kg]
Gross weight [kg]
2500
6100
1500
7600
2500 **
5800
7600
3500
6100
7600
3500 **
5800
7600
4500
7850
9300
Implement
Drawbar load [kg]
2500
At least 4% of the weighed weight.
3500
4500
