LEMKEN Primus-12 - Spraying Fluid System

Technical data
236
Type
P 260
P 200/P200
Pressure in accumulator [bar]
Optimum:
Pressure in accumulator = spray pres-
sure
Around:
 4 bar at a spray pressure of 1 – 10
bar
 6 bar at a spray pressure of 5 – 15
bar
Rated speed [rpm]
540
Speed range [rpm]
450 - 700
Output [rpm]
260
2 x 200
Flow rate at 5 bar and rated speed
[l/min]
520
400
Power consumption[KW] at rated speed
and 5 bar
10.2
7.1
Oil type
SAE 15W40
Approximate oil quantity [l]
1.7
2 x 1.3
Approximate weight [kg]
56.0
50.0
Membrane material
Rubber
Number of pressure accumulators
1
2
11.12 Spraying fluid system
Spraying pressure range of implement with water [bar]:
1.0 – 8.0
Permissible system pressure [bar]
10
Application quantity depending on pump, nozzles and speed of
travel [l/ha]:
200 – 600
