LEMKEN Primus-12 - Attaching the Implement with Cross Shaft

Preparations
97
6.4.2 Attaching the implement with cross shaft
 Switch the tractor's hydraulic system to
position control mode.
 Back the tractor straight up to the im-
plement.
 ATTENTION: Do not slide the device in
the process. If the device is on the sup-
port legs, moving the device may dama-
ge them.
 ATTENTION: Secure the lower link
against knocking up in case of negative
drawbar load.
o The lower links (1) are under
the cross shaft (2).
 Connect lower links of the tractor to the
cross shaft.
 Depending on the equipment, the catching sockets must be
secured.
 Secure the tractor against rolling over.
 Secure cross shaft in the lower links.
 Follow the tractor operating instructions.
2
1
