11.6.4 Track width
The listed track widths have a tolerance range of +/- 30 mm due to manufacturing
tolerances.
The width of the tyres reduces the possible range of the adjustable tracks.
Track width for specified tyres
Imple-
ple-
ment
Tyres *
Track width [mm] **
Minimum
Maximum
Primus 2500/3500
270/95 R48 145 A8
1500
2250
300/95 R46 148 A8
340/85 R46 150 A8
1550
420/85 R38 144 D
1600
460/85 R38 167 A8
1650
Primus 4500
270/95 R54 159 A8
1600
2250
300/95 R52 159 A8
340/85 R48 159 A8
1650
380/90 R46 175 A8
420/80 R46 162 A8
1700
460/85 R42 169 A8
1750
* Tyre specification using the example 270/95 R48 145 A8:
270
Nominal width [mm]
95
Height/Width ratio of a tyre
R
Radial tyres
48
Nominal diameter in inches (25.4 mm)
145
Load index (LI)
A8
Speed index (SI) for 40 km/h
** The maximum width of a tyre according to ETRTO was taken into account
for the track width.
