 Spray height above the crop approx. 60 cm.
 Spray pressure range 1.0 to 4.0 bar
 The data and applications listed in the nozzle tables must always be taken into
account.
12.7 Layout plan for electrohydraulic operation;
Positioning the hydraulic valves
Implement without Comfort FS equipment: Sprayer boom is controlled with
electrohydraulic operation.
Implement with Comfort FS equipment: Sprayer boom is operated with the control
system.
Raising and lowering the boom
Raise
Lower
Completely folding the boom or arm 1
Extend
Fold in
Folding arm 2
Extend
Fold in
Hydraulic slope compensation
