Technical data
225
Weighing is required to determine the exact tare weight.
 The maximum load capacities of the implement are listed on its type plate.
 If the load capacity of the wheels is lower than the stated axle loads, the per-
missible axle load shall be reduced in accordance with the load capacity of the
wheels, taking into account the permissible maximum speed.
 The permissible gross weight must also be reduced in accordance with the
permissible axle load.
11.3 Drawbar
Maximum permissible (technologi-
cally):
 Drawbar load [kg]:
1750
 Tractor mass [kg]:
13500
 D value [Kn]:
50.30
 Highest speed [km/h]:
40
 Inclination of the drawbar suspen-
sion
± 4° (adjustable)
11.4 Connecting fixture and drawbar extension
The drawbar is installed to be rigid or
spring-loaded. The drawbar has an inter-
face for a drawbar extension.
For the drawbar or the drawbar extension,
the following connecting fixtures are provi-
ded for:
Traction loops
Ring coupling
Ball coupling
40 mm Ø
50 mm Ø
K 80, straight
40 mm Ø,
cranked *)
Ring coupling 50 mm Ø,
cranked *)
K 80,
cranked downwards *)
Ring coupling 50 mm Ø,
rotatable
