LEMKEN Primus-12 - Filter; Tank Volume

Technical data
239
11.15 Filter
Diameter
[cm]
Length/Depth
[cm]
Screen area
[cm²]
Mesh width
[mm]
Suction filter
7.8
16.5
225.00
0.36
Filter on
filling hose
17.5
6.0
329.87
1.00
Press filter
5.0
21.0
192.00
0.25
11.16 Tank volume
Implement
Main tank
Clean water
tank * [l]
Hand-
washing
tank [l]
Nominal volume
[l]
Actual volume
[l]
2500
2300
2450
320 / 420
12
3500
3200
3400
320 / 420
12
4500
4200
4410
320 / 420
12
* Depending on the implement equipment: Clean water tank 320 l or 420 l.
 The listed volumes refer to water with a density of 1 kg/l.
 The containers may only be filled up to the permissible axle load.
 If the load capacity of the wheels is lower than the permissible axle load, the
permissible axle load shall be reduced to the permissible load capacity of the
wheels.
 Please note that when spraying heavier agents (e.g. AHL) the filling quantity of
the containers must be reduced.
