128
7.5 Adjust flush valve
Targets:
Pressure filter does not clog.
Flushing valve adjustment (1) matches
distribution rate[l/ha].
Application: Configure automatic distribu-
tion.
Additional information: Dirt particles col-
lected by the pressure filter are returned to
the main tank via the rinsing valve and the
agitator.
ATTENTION: When adjusting the rinsing
valve, diluted spraying agent emerges from
the nozzles.
Adjust flush valve on an unsealed
surface
Recommendation: Intended spray area
Preconditions:
Control is set on the basis of the instal-
led nozzles and the corresponding do-
sing table.
The intended travel speed (km/h) and
spray rate (l/ha) are known.
The required spray pressure is deter-
mined.
