Technical data
237
Connections
Hand washing container:
 Drain: Hose connector Ø 13 mm
 Filling GeKa connector
Fresh water tank
(Fresh water tank filling and
emptying connections):
GeKa connector
External cleaning/pumping:
1.5" Kamlock connector
Suction connector
2" Kamlock connector
Filling connector
2" Kamlock connector
Filling connection, capacity
Maximum filling capacity [l/min]:
500
Maximum filling pressure [bar]:
5
Suction connection, capacity
Maximum vacuum pressure [bar]:
- 0.3
Maximum suction height [m]
3
Minimum suction hose diameter [mm]:
2
Maximum suction hose length with hose at ground level [m]:
20
Filler hose
Connection to implement:
2" Kamlock connector
Length of hose
5 m or 8 m
Hose end:
Filter sieve 4" or 2" Kamlok connector
11.13 Oil hydraulic system
For the connection overview of the hydraulic hoses, see «, page
25».
