Implement with hydraulic braking system:
Manually pull the break away cable (2).
or
Open the brake valve (3).
Release break away cable from the trac-
tor.
Unlock the pin at the parking position (1)
and remove it.
Dismantle (2) supporting leg.
Install supporting leg (2) in the parking
position.
Insert bolts (3) in the safety borehole
and secure them.
Extend the parking support (1) with the
crank (4) until the correct height for un-
coupling is reached.
