Layout and description
68
5.11.9 Pressure limiting valve
The pressure limiting valve (1) is used to
adjust the maximum system pressure of
the implement.
The pressure limiting valve is set at the
factory and must not be adjusted.
5.11.10 Drain valve handwashing tank
The handwashing tank can be
emptied via the drain valve (1).
5.11.11 Fill level indicator and TANK control
The fill level indicator (1) is visible on the
main tank.
As an option, the contents of the main con-
tainer can also be viewed in the control
unit and at the control centre via a separa-
te display unit (2).
1
1
1
