Raise the implement before folding it up
Background:
When the machine moves, the sprayer
boom swings.
To allow the sprayer boom to be placed in
the storage pockets, the sprayer boom is
raised up to the stop of the lifting boom be-
fore folding.
Before the folding process:
To bring the sprayer boom into the hori-
zontal position:
Press the softkey.
The "folding" mask opens.
Press the softkey.
Press and hold the softkey until the
sprayer boom has reached the stop on
the lift mast boom.
Release softkey.
The sprayer boom is realigned.
After the sprayer boom has reached the
topmost position on the lift mast and is
aligned, the sprayer boom can be folded.
