154
The “folding“ mask opens.
Press the softkey.
Press and hold the softkey until the
sprayer boom has reached the stop on
the lift mast boom.
Release softkey.
The sprayer boom is realigned.
After the sprayer boom has reached the
topmost position on the lift mast and is
aligned, the sprayer boom can be folded.
For information on how to start up and shut
down the sprayer booms in general with
the control unit, refer to the operating ma-
nual SPRAYER-Controler MIDI 3.0 in
Chap. 6.2.4.
Folding in the boom
For information on how to fold in the spra-
yer boom with the control unit, refer to the
operating instructions for the sprayer con-
trol unit MIDI 3.0 in Chap. 6.2.3.
