157
The spray pump (H) draws the water from
the clean water tank via the switching val-
ve (C), the selection valve (A) and the suc-
tion filter (9). The water is then pumped to
the nozzles via the diverting valve (D) and
the pressure filter (3).
Procedure
Switch off pump (H) via PTO shaft.
Close flushing valve (F).
Remember the number of turns to close
the valve.
This adjustment is required after the sys-
tem has been cleaned.
Switch the selection valve of the spray
pump (A) to change-over valve (C).
Switch the switchover valve (C) to the
clean water tank.
Switch the diverting valve (D) to
spraying.
Close agitator regulation (E).
In the control: Manual mode for control-
ling the distribution rate.
To close the control valve (2):Press and
hold softkey for 10 seconds.
