Remaining spray agent is drained from
the pressure filter (1) and system
through the rinsing valve.
Flushing valve (F) closed to the limit po-
sition by turning it to the right.
Loosen the union nut (2) of the pressure
filter.
Remove the pressure filter.
Clean the individual components with
water and a soft brush.
Install press filter.
When mounting, ensure the seal (3) is
correctly inserted and not crushed.
Open flushing valve (F) if necessary.
