Maintenance and repairs

198

Pivot joint 1

 Lubricate 4 grease nipples on pivot joint

1 (1).

Pivot joint 2

 Lubricate 4 grease nipples on pivot joint

2 (1).

 Lubricate 2 grease nipples on strut (2).
