Layout and description
66
 Container (1)
The container can be swivelled in work-
ing and transport positions.
 Induction fitting (2)
including the following valves:
Agitator nozzle (3) for dissol-
ving and mixing spraying
agents.
Edge moistening (4) for:
 Spray spraying agent.
 Clean induction gate.
Canister flushing nozzle (5)
to clean empty spraying -
agent canister.
Cleaning gun (6)
The valves are continuously adjustable.
 Canister flushing nozzle (7)
Empty spray agent canisters can be rin-
sed out with the canister flushing nozzle.
The cleaning intensity can be varied u-
sing the valve canister flushing nozzle
(3).
 Agitator nozzle (8)
The agitator nozzle allows the spray
agent to be dissolved and pre-mixed.
 Edge moistening (9)
Edge moistening prevents spraying
agents from adhering to the induction
bowl.
8
7
3
2
1
6
5
4
9
