Preparations
87
Consumer
EW
DW
DR
LS
Connector co- lour
Code
Required quantity of oil [l/min]
Sprayer boom height ad-
justment
x
Blue
P1
18
Boom flaps
x
Green
P2/T2
10
Manual tiller steering system
x
White
P11/T1
1
Hydraulic pump drive
x
x
Yel-
low/white
P7/T7
Electro-hydraulic operation
x
x
Yel-
low/white
P6/T6
24
Electro-hydraulic operation
x
red
LS
EW = single-acting control unit
DW = double-acting control unit
DR = pressure-free return flow
LS = load-sensing signal cable
Requirements on tractor connection points
To ensure safe cornering when connected to the trailer coupling, the following to-
lerances must be observed in relation to the cardan shaft stub on the tractor.
