May 14, 2013
• Updated the Transfer roll removal procedure.
• The following Option‑related topics were added:
– Output expander diverter removal
– Output expander bin full flag removal
– HCOE bin full flag removal
– HCOE top diverter spring removal
– HCOE diverter plunger assembly removal
April 29, 2013
• Added the Security reset jumper topic to Appendix A.
April 17, 2013
• Changed Miscellaneous cooling fan service check to Fuser cooling fan service check.
• Added Fuser cooling fan removal procedure.
• Added part numbers 40X8803 and 40X8804 to Duplex parts catalog assembly.
• Updated Japan power cord part number.
• Deleted duplicate and inapplicable entries in Miscellaneous parts catalog assembly.
• The following Option‑related topics were added:
Output expander option removals
– Output expander option latch removal
– Output expander diverter motor removal
– Output expander diverter plunger assembly removal
– Output expander main motor removal
– Sensor (OE rear door interlock) removal
– Sensor (OE diverter plunger HP) removal
– Output expander diverter spring removal
– Output expander drive belt removal
– Output expander belt tensioner removal
– Output expander bin removal
– Sensor (OE pass through) removal
High capacity output expander option removals
– HCOE latch removal
– HCOE diverter motor removal
– Sensor (HCOE tray HP) removal
– HCOE tray spring removal
– HCOE tray pinion removal
– Sensor (HCOE rear door interlock) removal
– HCOE drive belt removal
– HCOE belt tensioner removal
