User Manual IEC 61850 Protocol Testing • 110
...........SIUnit
Specifies if the readings/settings are in °C or °F
CHxSTMPx.Alm.stVal value changes
at 1 degree greater and 1 degree
less than this value
...........multiplier
..........minVal
...........i
..........maxVal
...........i
........Tmp
Probe Temperature
..........mag
...........f
Magnitude of the Temperature
Note: Floating Point Number - Can
be in °C or °F
..........q
Validity Good / Validity Invalid
..........t
........ChnEnb
Temperature Proble Channel Enable
..........ctlVal
Entry for new Proble Channel Enable Value
..........stVal
Present Status
..........q
..........t
........SigStrnAlrmSetPt
Signal Strength Alarm Setpoint
Note: IEC61850 only - Effects
CHxSTMPx.SigStrnAlrm.stVal and
therefore bcrbCHANTMPALRM
Note: IEC61850 only - Does NOT
affect default LumaSmart SSR
operation
..........ctlVal
Entry for new Signal Strength Alarm Setpoint
...........i
..........mxVal
...........i
Present Probe Signal Strength
..........ctlNum
Present Probe Signal Strength Alarm Setpoint
..........q
Validity Good / Validity Invalid
..........t
..........ctlModel
..........minVal
...........i
10
..........maxVal
...........i
100
........SigStrnAlrm
Signal Strength Alarm
..........stVal
Present Status of Signal Strength Alarm
Note: IEC61850 only - Also see
ucrbCHANSIGALRM
..........q
Validity Good / Validity Invalid
..........t
