LumaSense LumaSMART User Manual

LumaSMART
®
User Manual IEC 61850 Protocol Testing • 112
........RstrSetPt
Restore threshold Setpoint
(Temperature)
..........setMag
...........i
Entry of new for Restore Threshold
Note: Must be less
than…AlrmSetPt.setMag.i
........RefTemp
Reference Temperature
See Section
..........instMag
...........f
..........q
........ChnxStat
Temperature Channel Inclusion Status
Note: x is the Relay number
0->16
..........ctlVal
Entry to Include (True) or Exclude (False)
Note: Set True if this Temperature
Channel is to be used to control this
Relay
..........stVal
Present Inclusion status
7.8.3 IEC61850 FOT Setup and Status Monitoring
Note: Max value depends on the LumaSMART configuration
Table 12: IEC61850 FOT Setup and Status Monitoring
.......FOTxCSWIx...................
Where x is the FOT number 1-> 4
........Mod
Mode
..........stVal
..........q
Validity Good / Validity Invalid
..........t
..........ctlModel
status-only
........Beh
Behavior
..........stVal
on
..........q
Validity Good / Validity Invalid
..........t
........Health
Channel Health
..........stVal
..........q
Validity Good / Validity Invalid
..........t
........NamPlt
Name Plate
..........vendor
LumaSense Technologies, Inc.
..........swRev
..........d
Channel Name
