7.8 IEC61580 Register Maps
Note: x is the Channel number: 1 > 16 (Max depend on LumaSmart configuration)
7.8.1 IEC61850 Temperature Channel Control and Supervision
Table 10: IEC61850 Temperature Channel Control and Supervision
.......CHxSTMPx
Temperature Channel Supervision
........Mod
Mode
..........stVal
..........q
Validity Good / Validity Invalid
..........t
..........ctlModel
status-only
........Beh
Behavior
..........stVal
on
..........q
Validity Good / Validity Invalid
..........t
........Health
Channel Health
..........stVal
..........q
Validity Good / Validity Invalid
..........t
........NamPlt
Name Plate
..........vendor
LumaSense Technologies, Inc.
..........swRev
..........d
Channel Name
Note: Can only be set locally on the
LumaSMART
.........Loc
..........stVal
Status Value of the Channel Alarm
..........q
Validity Good / Validity Invalid
..........t
........Alm
Individual Channel Temperature Alarm
..........stVal
Status Value of the Channel Alarm
Note: See ucrbCHANSIGALRM
(IEC61850 only)
..........q
Validity Good / Validity Invalid
..........t
........TmpAlmSpt
Temperature Alarm Set Point
Note: IEC61850 only - Effects
CHxSTMPx.Alm.stVal and therefore
ucrbCHANSIGALRM
Note: Interger -
..........setMag
...........i
Entry for new Alarm Temperaure
..........units
