LumaSense LumaSMART User Manual

LumaSMART
®
User Manual Modbus Protocol Testing • 89
6.5 Modbus Register Map
6.5.1 Modbus Coil Status
Table 6: Modbus Coil Status
Address 01 - Read Coil Status Data Type
0
System Status Relay
1 = Energized 0 = Deenergized
Binary Bool
1
Status for Relay 1
1 = Energized 0 = Deenergized
Binary Bool
2
Status for Relay 2
1 = Energized 0 = Deenergized
Binary Bool
3
Status for Relay 3
1 = Energized 0 = Deenergized
Binary Bool
4
Status for Relay 4
1 = Energized 0 = Deenergized
Binary Bool
5
Status for Relay 5
1 = Energized 0 = Deenergized
Binary Bool
6
Status for Relay 6
1 = Energized 0 = Deenergized
Binary Bool
7
Status for Relay 7
1 = Energized 0 = Deenergized
Binary Bool
8
Status for Relay 8
1 = Energized 0 = Deenergized
Binary Bool
9
Status for Relay 9
1 = Energized 0 = Deenergized
Binary Bool
10
Status for Relay 10
1 = Energized 0 = Deenergized
Binary Bool
11
Status for Relay 11
1 = Energized 0 = Deenergized
Binary Bool
12
Status for Relay 12
1 = Energized 0 = Deenergized
Binary Bool
13
Status for Relay 13
1 = Energized 0 = Deenergized
Binary Bool
14
Status for Relay 14
1 = Energized 0 = Deenergized
Binary Bool
15
Status for Relay 15
1 = Energized 0 = Deenergized
Binary Bool
16
Status for Relay 16
1 = Energized 0 = Deenergized
Binary Bool
17-63
Reserved for future expansion
Binary Bool
