User Manual IEC 61850 Protocol Testing • 111
7.8.2 IEC61850 Relay Channel Control and Supervision
Table 11: IEC61850 Relay Channel Control and Supervision
.......RxCSWIx
Relay Channel Supervision and Control
........Mod
Mode
..........stVal
..........q
Validity Good / Validity Invalid
..........t
timestamp
..........ctlModel
status-only
.......Beh
Behaviour
..........stVal
on
..........q
Validity Good / Validity Invalid
..........t
timestamp
........Health
Channel Health
..........stVal
OK
..........q
Validity Good / Validity Invalid
..........t
timestamp
........NamPlt
Name Plate
..........vendor
LumaSense Technologies, Inc.
..........swRev
..........d
Relay Name description
Note: Value can only be set locally at the
LumaSmart
........Pos
..........stVal
Present Status of the System Status
Relay (Position)
Note: Also shown in report
bcrbRELAYSTAT.RxCSWIx.Pos.stVal
..........q
Validity Good
..........t
timestamp
..........ctlModel
........RelLogic
Relay Logical Control
..........ctlVal
Entry of new Status Relay Logical Control
Note: True = "OR Function" ; False =
"AVG Function"
..........stVal
Present Status of Relay Logical Control
........RelCfg
Relay Configuration
..........ctlVal
Entry of new Relay Configuration
Note: 0 = "Disabled" : 1 = "Normally
Deenergized" : 2 = "Normally
Energized"
..........stVal
Present Status of Relay Configuration
........AlrmSetPt
Alarm threshold Setpoint (Temperature)
..........setMag
...........i
Entry of new for Alarm Threshold
Note: Must be greater
than...RstrSetPt.setMag.i
