LumaSense LumaSMART User Manual

LumaSMART
®
User Manual DNP3 Protocol Testing • 137
86
Relay Configuration for Relay 15
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #15
87 Alarm Setpoint for Relay 15 Int32
88 Restore Setpoint for Relay 15 Int32
89
Logic for Relay 15
2 = OR … 1 = AVG ... 0=None
Uint32
90
Channel Temperature Inputs for Relay15
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
91
Relay Configuration for Relay 16
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #16
92 Alarm Setpoint for Relay 16 Int32
93 Restore Setpoint for Relay 16 Int32
94
Logic for Relay 16
2 = OR … 1 = AVG ... 0=None
Uint32
95
Channel Temperature Inputs for Relay 16
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
8.8.4 DNP 3 Analog Input Map
Table 21: DNP 3 Binary Input Map
PointId Parameter Data Type
0
Temperature value for Channel 1
Float
1
Signal Strength for Channel 1
Float
2
Temperature value for Channel 2
Float
3
Signal Strength for Channel 2
Float
4
Temperature value for Channel 3
Float
5
Signal Strength for Channel 3
Float
6
Temperature value for Channel 4
Float
7
Signal Strength for Channel 4
Float
8
Temperature value for Channel 5
Float
9
Signal Strength for Channel 5
Float
10
Temperature value for Channel 6
Float
11
Signal Strength for Channel 6
Float
12
Temperature value for Channel 7
Float
13
Signal Strength for Channel 7
Float
14
Temperature value for Channel 8
Float
15
Signal Strength for Channel 8
Float
16
Temperature value for Channel 9
Float
17
Signal Strength for Channel 9
Float
18
Temperature value for Channel 10
Float
19
Signal Strength for Channel 10
Float
20
Temperature value for Channel 11
Float
21
Signal Strength for Channel 11
Float
