LumaSense LumaSMART User Manual

LumaSMART
®
User Manual DNP3 Protocol Testing • 131
8.8 DNP3 Register Map
8.8.1 DNP 3 Binary Output Map
Table 18: DNP 3 Binary Output Map
PointId Parameter Data Type
0
Status for Channel Number 1
1 = Enable 0 = Disable
Binary
Bool
Enable/Disable Temperature Channel
1
Status for Channel Number 2
1 = Enable 0 = Disable
Binary
Bool
2
Status for Channel Number 3
1 = Enable 0 = Disable
Binary
Bool
3
Status for Channel Number 4
1 = Enable 0 = Disable
Binary
Bool
4
Status for Channel Number 5
1 = Enable 0 = Disable
Binary
Bool
5
Status for Channel Number 6
1 = Enable 0 = Disable
Binary
Bool
6
Status for Channel Number 7
1 = Enable 0 = Disable
Binary
Bool
7
Status for Channel Number 8
1 = Enable 0 = Disable
Binary
Bool
8
Status for Channel Number 9
1 = Enable 0 = Disable
Binary
Bool
9
Status for Channel Number 10
1 = Enable 0 = Disable
Binary
Bool
10
Status for Channel Number 11
1 = Enable 0 = Disable
Binary
Bool
11
Status for Channel Number 12
1 = Enable 0 = Disable
Binary
Bool
12
Status for Channel Number 13
1 = Enable 0 = Disable
Binary
Bool
13
Status for Channel Number 14
1 = Enable 0 = Disable
Binary
Bool
14
Status for Channel Number 15
1 = Enable 0 = Disable
Binary
Bool
15
Status for Channel Number 16
1 = Enable 0 = Disable
Binary
Bool
