User Manual IEC 61850 Protocol Testing • 114
........Health
Channel Health
..........stVal
..........q
Validity Good / Validity Invalid
..........t
........NamPlt
Name Plate
..........vendor
LumaSense Technologies, Inc.
..........swRev
..........d
System Status Relay
........Pos
Position
..........stVal
Present Status of the the Relay
(Position)
Note: Also shown in report
bcrbRELAYSTAT.SSRCSWI0.Pos.stVal
..........q
Validity Good / Validity Invalid
..........t
..........ctlModel
7.8.5 IEC61850 General System Configuration Information
Table 14: IEC61850 General System Configuration Information
FRVCSWI1....................
General System Configuration information
........Mod
Mode
..........stVal
..........q
Validity Good / Validity Invalid
..........t
..........ctlModel
status-only
........Beh
Behaviour
..........stVal
on
..........q
Validity Good / Validity Invalid
..........t
........Health
Channel Health
..........stVal
..........q
Validity Good / Validity Invalid
..........t
........NamPlt
Name Plate
..........vendor
LumaSense Technologies, Inc.
..........swRev
..........d
........Pos
Not Implemented
..........stVal
intermediate-state
..........q
..........t
..........ctlModel
status-only
