LumaSense LumaSMART User Manual

LumaSMART
®
User Manual Modbus Protocol Testing • 96
134
Configuration Relay 15
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 15
135 Alarm Set Point for Relay 15 Int16
136 Restore Set Point for Relay 15 Int16
137
Channels Driving Relay 15
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
138
Control Setting for Relay Number 15
2 = OR Logic
1 = AVG Logic
Int16
139
Configuration Relay 16
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 16
140 Alarm Set Point for Relay 16 Int16
141 Restore Set Point for Relay 16 Int16
142
Channels Driving Relay 16
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
143
Control Setting for Relay Number 16
2 = OR Logic
1 = AVG Logic
Int16
144 - 147
Reserved for future expansion
148
Temperature Channel Enable
1 = Enabled
0 = Disabled
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
149 - 240
Reserved for future expansion
6.5.4 Modbus Input Register
Table 9: Modbus Input Register
Address Parameter Data Type
0-1 Temperature value for Channel 1
Float
CD AB
Channel
1
2-3 Probe Signal Strength Channel 1
Float
CD AB
4 - 5 Temperature of Channel 2
Float
CD AB
Channel
2
6 - 7 Probe Signal Strength Channel 2
Float
CD AB
