LumaSense LumaSMART User Manual

LumaSMART
®
User Manual IEC 61850 Protocol Testing • 113
........Pos
Not Implemented
..........ctlVal
..........stVal
..........q
..........t
..........ctlModel
........LowCurrent
Lowest Current Value
..........setMag
...........f
Enter Current value for Probes are at
specified LowTemp
Note: See LowTemp Value Below
........HighCurrent
Highest Current Value
..........setMag
...........f
Enter Current value for Probes are at
specified HighTemp
Note: See HighTemp Value Below
........LowTemp
Lowest Temperature for Probe
Current Calculation
..........setMag
...........f
Enter Temperature associated with
specified Lowest Current value
Note: See Lowest Current Value above
........HighTemp
Highest Temperature for Probe
Current Calculation
..........setMag
...........f
Enter Temperature associated with
specified Highest Current value
Note: See Highest Current Value above
7.8.4 IEC61850 System Status Relay Report
Table 13: IEC61850 System Status Relay Report
.......SSRCSWI0
System Status Relay Node
........Mod
Mode
..........stVal
..........q
Validity Good / Validity Invalid
..........t
..........ctlModel
status-only
........Beh
Behaviour
..........stVal
on
..........q
Validity Good / Validity Invalid
..........t
