LumaSense LumaSMART User Manual

LumaSMART
®
User Manual DNP3 Protocol Testing • 136
61
Relay Configuration for Relay 10
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #10
62
Alarm Setpoint for Relay 10
Uint32
63
Restore Setpoint for Relay 10
Uint32
64
Logic for Relay 10
2 = OR … 1 = AVG ... 0=None
Uint32
65
Channel Temperature Inputs for Relay 10
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
66
Relay Configuration for Relay 11
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #11
67
Alarm Setpoint for Relay 11
Int32
68
Restore Setpoint for Relay 11
Int32
69
Logic for Relay 11
2 = OR … 1 = AVG ... 0=None
Uint32
70
Channel Temperature Inputs for Relay 11
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
71
Relay Configuration for Relay 12
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #12
72
Alarm Setpoint for Relay 12
Int32
73 Restore Setpoint for Relay 12 Int32
74
Logic for Relay 12
2 = OR … 1 = AVG ... 0=None
Uint32
75
Channel Temperature Inputs for Relay 12
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
76
Relay Configuration for Relay 13
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #13
77 Alarm Setpoint for Relay 13 Int32
78 Restore Setpoint for Relay 13 Int32
79
Logic for Relay 13
2 = OR … 1 = AVG ... 0=None
Uint32
80
Channel Temperature Inputs for Relay 13
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
81
Relay Configuration for Relay 14
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #14
82 Alarm Setpoint for Relay 14 Int32
83 Restore Setpoint for Relay 14 Int32
84
Logic for Relay 14
2 = OR … 1 = AVG ... 0=None
Uint32
85
Channel Temperature Inputs for Relay 14
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
