User Manual DNP3 Protocol Testing • 135
36
Relay Configuration for Relay 5
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #5
37
Alarm Setpoint for Relay 5
Int32
38 Restore Setpoint for Relay 5 Int32
39
Logic for Relay 5
2 = OR … 1 = AVG ... 0=None
Uint32
40
Channel Temperature Inputs for Relay 5
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
41
Relay Configuration for Relay 6
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #6
42 Alarm Setpoint for Relay 6 Int32
43
Restore Setpoint for Relay 6
Int32
44
Logic for Relay 6
2 = OR … 1 = AVG ... 0=None
Uint32
45
Channel Temperature Inputs for Relay 6
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
46
Relay Configuration for Relay 7
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #7
47
Alarm Setpoint for Relay 7
Int32
48
Restore Setpoint for Relay 7
Int32
49
Logic for Relay 7
2 = OR … 1 = AVG ... 0=None
Uint32
50
Channel Temperature Inputs for Relay 7
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
51
Relay Configuration for Relay 8
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #8
52
Alarm Setpoint for Relay 8
Int32
53
Restore Setpoint for Relay 8
Int32
54
Logic for Relay 8
2 = OR … 1 = AVG ... 0=None
Uint32
55
Channel Temperature Inputs for Relay 8
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
56
Relay Configuration for Relay 9
0 = Disabled
1 = Normally DeEnergized
2 = Normally Energized
Uint32
Relay #9
57
Alarm Setpoint for Relay 9
Int32
58 Restore Setpoint for Relay 9 Int32
59
Logic for Relay 9
2 = OR … 1 = AVG ... 0=None
Uint32
60
Channel Temperature Inputs for Relay 9
Bit Mapped (Bit 15 = Channel 16 … Bit 0 = Channel 1)
Uint32
