Board Design Guidelines for SmartFusion2 SoC and IGLOO2 FPGAs
AC393 Application Note Revision 14.0 15
Table 6 • Recommendation for Bank Supplies for FC1152, FG896, FG676, FCS536, FCV484 Packages
1
Bank
Supply
Names
FC1152 FG896 FG676 FCS536 FCV484
M2S150T/
M2GL050T
M2S050T/
M2GL050T
M2S090T/
M2GL090T
M2S060T/
M2GL060T
M2S150T/
M2GL150T
M2S150T/
M2GL150
VDDI0 Connect to VSS through a 10 k
Ω resistor –
VDDI1 Connect to VSS through
a 10 k
Ω resistor
Must connect
to VDDI1
Connect to VSS through a 10 k
Ω resistor
VDDI2 Connect to VSS through
a 10 k
Ω resistor
Must connect
to VDDI2
Must connect
to VDDI2
Must connect
to VDDI2
Connect to VSS through a 10 k
Ω resistor
VDDI3 Connect to VSS through
a 10 k
Ω resistor
Must connect
to VDDI3
Must connect
to VDDI3
Must connect
to VDDI3
Connect to VSS through a 10 k
Ω resistor
VDDI4 Connect to VSS through a 10 k
Ω resistor Must connect
to VDDI4
Connect to VSS through a 10 kΩ resistor
VDDI5 Connect to VSS through a 10 k
Ω resistor
VDDI6 Must connect to VDDI6 Connect to VSS through a 10 kΩ resistor Must connect to
VDDI6
Must connect to
VDDI6
VDDI7 Must connect to VDDI7 Connect to VSS through a 10 k
Ω resistor Must connect to
VDDI7
Must connect to
VDDI7
VDDI8 Connect to VSS through a 10 k
Ω resistor –
VDDI9 Connect to VSS through a 10 kΩ resistor – Connect to VSS through a 10 kΩ resistor
VDDI10 Connect to VSS through
a 10 k
Ω resistor
–––Connect to VSS through a 10 k
Ω resistor
VDDI11 Connect to VSS through
a 10 k
Ω resistor
–––Connect to VSS through a 10 k
Ω resistor
VDDI12 Connect to VSS through
a 10 k
Ω resistor
–––Connect to VSS through a 10 k
Ω resistor
VDDI13 Connect to VSS through
a 10 k
Ω resistor
–––Connect to VSS through a 10 k
Ω resistor
VDDI14 Connect to VSS through
a 10 k
Ω resistor
–––Connect to VSS through a 10 k
Ω resistor
VDDI15 Connect to VSS through
a 10 k
Ω resistor
–––Connect to VSS
through a 10 kΩ
resistor
–
VDDI16 Connect to VSS through
a 10 k
Ω resistor
–––Connect to VSS through a 10 k
Ω resistor
VDDI17 Connect to VSS through
a 10 k
Ω resistor
–––Connect to VSS through a 10 k
Ω resistor
VDDI18 Connect to VSS through
a 10 k
Ω resistor
–––Connect to VSS
through a 10 kΩ
resistor
–
1. The unused VDDI# pins must be connected to VSS through a 10 KΩ resistor. The VDDI# pins can be grouped and connected to
one 10 KΩ resistor or a 10 K Ω resistor can be used for each VDDI# bank, it completely depends on the board layout. For the
previous design the unused VDDI# pins were DNC, and cannot create functionality issue. Microsemi recommends connecting to
Ground to improve the board reliability.
