MIMAKI JV330 Series User Manual

Chapter 4 Cutting Data with Register Marks
114
Spacing Between Register Marks
The spacing between register marks (C) is as shown below.
(Mark shape) Type 1 (Mark shape) Type 2
Register mark length (B) x 2 + α, up to 1,000 mm
(C)
(B)
(B)
(C)
Register mark length (B) + α, up to 1,000 mm
(C)(B)
(B)(C)
l
Mark Origin Mis-detection Example
• If the spacing between register marks (C) is narrow, as shown in the figure below, the machine may fail
to detect them.
(B)(C)
(B) (C)
