Chapter 2 Printing
77
2.5 Setting the Pressure and Number of
Pinch Rollers to Use
Set the pressure and number used to hold media based on the tool and media being used. Incorrect pinch
roller pressure settings may result in media skew or leave pinch roller marks on the media.
• JV/TS: Feature not included.
1
On the LOCAL mode screen, select [PR].
width:1340mm
PRTOOL
TEST CUT
LOCAL
2
Make settings based on the tool and media used.
• The following items can be configured:
• The settings are retained even when the power is turned off.
Item Setting Overview
Number for Use 2 or more (depending
on size)
Sets the number of pinch rollers to use.
Print LOW/MID/HIGH Sets the pressure used for printing.
Cut:Ends LOW/MID/HIGH Sets the pressure for both the pinch rollers on the edges
(left and right) used for cutting.
Cut:Inner OFF/LOW/MID/HIGH Sets the pressure for the pinch rollers used for printing
other than those on the edges.
Change Execution - Used to check settings. Switch to configured settings
before printing the built-in pattern (e.g., test printing, test
cutting).
2
To Next Page
