Chapter 6 Settings
168
6.3 Function Setting Menu
This is used to set various operations to ensure optimal machine performance.
l
Menu List
Item
Setting
*1
Details
Logical Seek Host/OFF/ON Sets the range of carriage movement.
• OFF: Machine size area
Unidirectional print Bi-directional print
Carriage movement
• ON: Print data area
Unidirectional print Bi-directional print
Print data
Carriage movement
Take-up Unit - Sets the take-up unit operation.
Take-up Unit ON/OFF Set to "OFF" if the take-up unit is not used.
Take-up SW Continuous/
Temporary
Sets the function performed by the ON/OFF button on the take-
up unit. "Take-up Unit"(P. 60)
• Continuous: Press the button to start/stop the take-up unit.
• Temporary: The take-up unit operates only while the button
is pressed. The unit stops when the button is released.
Drying Time - Sets the time for ink to dry.
Scan Host/0.0 to 9.9
sec
Sets the stop time of the carriage after each scan.
• The MIMAKI RIP software (RasterLink) indicates this as
"Pause Time per Scan".
Print End Host/0 to 120
min
Sets the stop time after printing. The next data is printed once
the set time has elapsed.
• The Mimaki RIP software (RasterLink) does not allow the
user to specify Print End. If the machine is set to "HOST",
the time will be "0".
Power Setting - Sets the times to turn the power on and off automatically.
Auto Power-off 5 to 15 to 60
min
Sets the time until the power is automatically turned off.
Auto Power-on - Sets the time to automatically turn on the power.
Setup ON/OFF Sets whether to turn on or off the power.
Time 0:00 to 23:59 Sets the time to turn on the power.
To Next Page
