Chapter 7 Maintenance
201
6
Mount a new cap.
• Position with the slot at the front and push in until it clicks.
7
Once replacement is complete, close the cover, then press the [ENTER] key.
Replacing the Absorber Around the Station
If the cap absorber or maintenance liquid absorber is very dirty or if ink drips on to the media, replace with a
new cap absorber.
With Resin Plate
1
On the LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2
Select [Station Maint.] > [Carriage Out] > [Move To Platen Right End], then press the [ENTER]
key.
• The carriage moves over the platen.
3
Open the maintenance cover on the right side.
4
Remove the cap absorber together with the plate.
• Push up the two tabs at the front to remove the cap absorber.
Cap absorber
Plate (resin plate)
• Avoid ink dripping when removing the cap absorber.
7
To Next Page
