Chapter 6 Settings
177
• Reset the origin before executing the copy function. Failure to do so will result in overlap cutting.
Copy end origin
Copy start origin (set manually)
Last cut data
(stored in the receive buffer)
Copy interval
Copy interval
• The machine cuts the specified number of sheets of the divided cut data without separating the
data.
• With the following data, only one sheet can be cut, regardless of the number of copies specified.
(1) Data received from MIMAKI RIP software (RasterLink).
(2) Data for which "Sheet Feed Origin Renewal" has been selected in the MIMAKI cutting
software (FineCut).
• When sending the cut data from the PC, wait for at least 5 seconds before sending the next
data. If the next data is sent within 5 seconds, both pieces of data may be copied.
Preventing Uncut Media
Overlapping the start and end points can prevent the media from being left uncut. Configure this setting for
very flexible media.
If the setting is too large, the print may also be cut. Check using a test cut ( "Test Cutting"(P. 106)) when
altering the setting.
l
Over Cut
The machine cuts the media in front of the cutting start point by the set value. The media is overcut by the
set value at the end point.
Over Cut: OFF Over Cut: 0.1 to 1.0 mm
l
Corner Cut
When the Over Cut setting value is entered, Corner Cut is displayed. The machine performs over cutting at
corners other than the start and end point.
Corner Cut: OFF Corner Cut: ON
6
To Next Page
