Chapter 5 Using the XY Slitter
136
6
Select the [XY Slitter Edit] check box on the Image Edit tab.
7
Select the slitting method for the Y (scan) direction.
• "None" is used when slitting only in the X (scan) direction.
8
Select the timing for slitting.
• Slit at the same time as printing: To slit simultaneously with printing.
• Slit Afterwards: To slit after printing.
9
Click [Print X-Cutter Reference line].
• Guide (slit) line printing starts.
• Do not print any other data after printing the guide (slit) line until the X cutter has been
mounted. Otherwise, the X cutter cannot be mounted.
Mounting the X cutter
• Do not touch the X cutter when the XY clamp lever is raised. Otherwise, you may get injured by
the moving XY carriage.
To Next Page
