Chapter 3 Cutting
94
3.1 Cutting Process
1.
Turn on the power.
"Turning On the Power"(P. 36)
2.
Connect this machine to the PC on which the cutting software is installed.
"Using a USB Cable"(P. 40)
"Using a LAN Cable"(P. 39)
3.
Adjust the pinch roller positions.
Adjust the pinch roller positions to suit the width of the set media. Adjust the pinch roller positions so that the
pinch rollers are positioned above the grit rollers. The pinch rollers at both ends should be aligned to within
10 cm from the left edges and 2 cm from the right edges of the media. "Adjust the Pinch Roller
Positions."(P. 56)
4.
Loading the media
This machine can be used with roll media and leaf media. "Load the media."(P. 59)
5.
Adjust the number and pressure of pinch rollers to use.
Set an appropriate pressure for the set media. "Setting the Pressure and Number of Pinch Rollers to
Use"(P. 77)
6.
Install the cutting tools.
This machine can be used with a cutter and a pen (ballpoint pen). "Installing Cutting Tools"(P. 96)
7.
Set the cutting speed and pressure.
Set the cutting speed and pressure to match the type of media and tools in use. "Setting the Cutting
Conditions"(P. 105)
8.
Perform test cutting.
Perform a test cut to confirm that the tool conditions are set appropriately. "Test Cutting"(P. 106)
To Next Page
