MIMAKI JV330 Series - XY Slitter Integration with Register Marks

Chapter 4 Cutting Data with Register Marks
120
When using the XY slitter
• When using slitting afterwards ( "Slitting the Print Media Afterwards"(P. 143)) in combination, set
"Offset X" ([MENU] > [Cutting] > [Mark Detect] > [Detect Area] > [Offset X] P. 174) so that this comes
after the XY slitter detection mark.
Not OK: Not set
Print data (second sheet)
Print data (first sheet)
[Offset X]: Set position
OK: Set
