Chapter 5 Using the XY Slitter
126
When set to [Normal] or [Line Space]
1
Place the media chute under the XY slitter.
2
Push the media chute front forward.
•
Remove the screws at the front of both sides. Be careful not to lose the screws.
•
Place so that the blank pieces cut off are ejected to the media chute.
•
Use the media support.
125
127
