Chapter 8 Troubleshooting
227
7
Check the following again.
• "Adjusting the Position of the Register Mark Sensor"(P. 225)
• If the buzzer does not sound four times, check the printed register mark conditions and contact
your local distributor, our sales office, or service center.
Investigating the Cause of Cutting Failures
1
On the LOCAL mode screen, select [MENU] > [Cutting], then press the [ENTER] key.
• The Cutting menu is displayed.
2
Select [Maintenance] > [Sample Cut], then press the [ENTER] key.
3
Select the sample data, then press the [ENTER] key.
• There are two sample types: "Cut" and "Logo".
• If you select "Cut", press the [ENTER] key to start cutting.
• If you select "Logo", refer to the following:
(1) Press to specify the scaling factor (1 to 999 %).
(2) Press the [ENTER] key to start cutting
• The settings are retained even if [Setup Reset] is selected.
l
Sample Cut Results
• Sample data can be cut properly, but not other data.
– There is a problem with the host PC.
• Sample data as well as other data cannot be cut properly.
– There is a problem with the printer. Increase the pressure in the Adj-prs Offset menu. "Cutting
Menu"(P. 174)
Adjusting to Correct Misalignment Between Printing and Cutting
In the procedure described below, MIMAKI RIP software (RasterLink) is used to print a correction pattern.
When printing and cutting, correction is required for each resolution in the scan (Y) direction. (The corrected
value is saved for each resolution.) Print a pattern for each resolution, then input the correction value.
1
Switch the machine to REMOTE mode.
2
Set the print conditions (profile/cut conditions) for the job you want to print in RasterLink.
• Specify the following settings by clicking the function icons shown on the right-hand side of the
screen:
(General Print): Specifies settings like enlargement/reduction and rotation.
(Quality): Selects a color profile for the media and ink set loaded in this machine.
• For more information, refer to the RasterLink reference guide. https://mimaki.com/
download/software.html
8
To Next Page
