System Introduction
4-8
(24)
/
Directional soft
menu controls
Up / down controls are used to turn pages up /
down when there are more-than-one pages for the
soft menu;
Left / right controls are used to switch between the
image modes.
(25)
/
Soft menu control Rotate to adjust the soft menu item displayed on
the bottom of the screen. Refer to the subsequent
content for specific function.
(26)
/
Soft menu control Rotate to adjust the soft menu item displayed on
the bottom of the screen. Refer to the subsequent
content for specific function.
(27) iTouch / Press to optimize the image, serving as a one-key
optimization.
(28) Info Patient
information
Press to enter the patient information input screen.
(29)
Probe
Probe
Press to open the [Select Probe & Exam] screen to
select the transducer and exam type.
(30) Review Review Press to review the image files stored.
(31) Report Report Press to show or hide a diagnosis report
(32)
End
Exam
End Exam
Press to end an exam.
(33)
F10
User-defined key You can assign a function to the key.
(34) Update Update
z Press to change the currently active
window in B+M or PW mode.
z Press to start or end image capture in
3D/4D or iScape mode.
(35) CW CW mode Press to enter the CW mode.
(36) M M mode Press to enter the M mode.
(37) PW PW mode Press to enter the PW mode.
To Next Page
