Chapter 5: Installation
Connecting Trunks to LSM-2 Module Ports
Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008 Page 5-23
Figure 5-2. Cabling Option 1 for the LSM-2
Figure 5-3. Cabling Option 2 for the LSM-2
1
2
3
4
5
6
not used
not used
T 1
R 1
T 2
R 2
8P/8C 110 Patch
8P/8C 110 Patch
66M1-50
Block
Adapter
6-pin plug
4- or 6-conductor
modular line cord
8P/8C 110 Patch Panel Back
1
2
T-1
2
35
6
7
8
9
10
11
12
13
14
15
16
17
18
R-1 T-2R-2
T-1 R-1 T-2R-2
1
2
3
468
57
3
4
LS 1
LS 2
SL 1
SL 2
8-pin Jack
6-pin Plug
RJ-14
to 8-pin jack
8-pin Jack
6-pin Plug
Adapter
NO YES
Chassis Back
RJ-14
T-1 R-1 T-2R-2
LS 4
LS 3
Dual Single Line PortLSM-2 Module
Panel Front
Panel Back
1
4
25-Pair
cable from
MDF to
patch panel
Dual Loop Start Port
1
2
3
4
5
6
not used
not used
T 1
R 1
T 2
R 2
4- or 6-conductor
modular line cord
RJ-14
RJ-14
2 modular jack
assemblies at rack
YEL
GND
BLK
WHT
R2
RED
R1
T2
BLU
T1
GRN
66M1-50
Block
For each modular jack assembly
Chassis Back
Top View
25-Pair cable
from MDF
to rack
