Chapter 5: Installation
Installing a Mini-DSS Unit
Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008 Page 5-181
Figure 5-68. Mini-DSS Installation
Figure 5-69. Model 8660 with Attached Mini-DSS
For illustration clarity, the endpoint base is not shown.
Mini-DSS
(Bottom)
8660 Endpoint
(Bottom)
Top Access Panel Cable Pin Connector
Bottom Access
Cable
(1¾”)
Panel
Mini-DSS
Faceplate
Endpoint Facemats
Mini-DSS
Facemats
