Chapter 6: Reference
SIP (Only) Softphone
Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008 Page 6-23
Figure 6-11. Eclipse IP PhonePlus
DC
BARREL JACK
HANDSET JACK
LCD CONTRAST KNOB
PORT 3
(DC and
LAN/
POWER
PORT 1
PORT 2
Bottom
LEDs
Front
Back
MESSAGE
LAMP
6-LINE LCD
MENU
DISPLAY
BUTTONS
SPEAKER
KEYPAD
MICROPHONE
(UNDERNEATH)
RING AND VOICE
VOLUME CONTROL
SPEAKER BUTTON
HOLD BUTTON
(RED)
SPECIAL BUTTON
CALL, INTERCOM,
AND
PROGRAMMABLE
BUTTONS
Center is
Positive)
