Chapter 11 METER SETTING
11.5 Compact Flash Setting （ F-53, 54, 55）
146 HORIBA
WRITE OPERATOR INFORMATION
Information such as Operator names or currently set configuration is copied onto the compact
flash card.
Personal data can be written only for one person per each CF card.
1. Press the ENTER key.
Personal data such as Operator name, meter configuration items, each setup item is
stored into the compact flash card.
FORMAT
The compact flash card is formatted.
Formatting will delete all the data previously stored.
1. Press ENTER key.
2. Press F4 (CONFIRM).
The formatting starts.
Since the formatting uses a part of memory, the empty capacity displayed will be smaller than
that mentioned in the compact flash card even though no data is stored.
11.5.4 Data acquisition to PC
To transfer the data from the compact flash card, the following tools are necessary:
●
PC
●
A compact flash card reader (those commercially available)
●
Software
The software is available by downloading from HORIBA’s website after user registration.
Fill in the User Registration Card separately attached to this manual to complete the
registration.
