Chapter 11 METER SETTING
11.6 Network Setting (F-55)
148 HORIBA
11.6 Network Setting (F-55)
The network setting requires knowledge on network administration.When setting other than
the standard configuration is necessary, or when a rooter or a hub should be used, consult with
the network administrator.
Communication regulation/Transmission speed
LAN (Ethernet) connector
RJ-45 modular connector
Use a cross cable for the Ethernet cable.
Internet address setting
This meter is conformed to the address of the Class C.
The setting range for the Internet address is:192.0.0.0 – 223.255.255.255
Among these addresses, the settings 192.0.0.0 - 192.0.0.255 and 223.255.255.0 –
223.255.255.255 are reserved for a specific usage as Class C regulation, and should not be
used. Setting these addresses as a network address may have an adverse influence to the
other network system.
Cautionary items for Internet address setting
In using IP address, a private address can be used in the environment unconnected to the
external Internet (specified by RFC1918).
The environment unconnected to the external Internet means the environment in which the
connection with the external network as Internet is not available using the same cable with
that connected to the printer or PC.
※ What is “private address?”
When the connection is not given to the external Internet, addresses in the range below can be
freely set, and these addresses are called “private address:”
192.168.0.0 − 192.168.255.255
The meter F-55 sets the standard IP address as follows: 192.168.0.1
Commu-
nication
Regula
-
tion
Regulation
IEEE802.3u （100BASE-TX）
IEEE802.3 （10BASE-T）
Transmis-
sion speed
100Mbps （100BASE-TX）
10Mbps （10BASE-T）
100BASE-TX
10BASE-T
(switch)
Automatic Negotiation
※ No manual setting is available.
Item Setting configuration (Standard
setting at Factory shipping)
IP address 192.168.0.1
Gateway address 192.168.0.100
Subnet mask 255.255.255.0
