Chapter 14 PRINTER
14.1 Printer Specification
F-52, 53, 54, 55 175
Chapter 14 PRINTER
14.1 Printer Specification
The printer is optional.
●
Baud Rate: 2400 bps
●
Word Length: 8 bits
●
Parity: None
●
Stop Bits: 1 bit
Setting for the plain paper printer (CBM-910)
Set the DIP switch No. 6 to ON and No. 7 to OFF, and then set printer paper and ink ribbon.
Keep the LF key held down.
Keep the LF key held down. The printer prints output when the LF key is being pressed.
Setting for thermal paper printer (DPU-H245AS)
Set printer paper and turn ON the power switch with the FEED and CHARGE switches held
down.
Startup the printer SETUP mode, to change to the above setting.
Refer to the instruction manual for the printer.
14.1.1Printer output timing
The printer prints at the following times.
●
① When pressing the ENTER key in the Measurement mode
(During AutoHold, no printout is available)
●
② When the manual data memory is performed in the Measurement mode.
●
③ When the printout is executed on the DATA OUT screen
●
④ When the printout is executed in the Calibration mode
●
⑤ When the printout is executed in the REPEATABILITY mode
●
⑥ When test printing is selected while in the Maintenance mode, a test is printed.
Type Model Manufacturer
Normal paper type CBM-910-24RJ100-A Citizen CBM
Heat-sensitive paper
type
DPU-H245AS-A03A SII
